Aramid filament fiber is a kind of strong continuous synthetic fiber coiled on bobbins. It is compatible with most types of polymer binders and can be utilized for ballistic rated body armor fabric and composites materials. The regular color is yellow.
Product Features:
• Good thermal stability
• Outstanding strength-to-weight ratio
• High tenacity and high modulus
• Resistance to heat, flame and chemicals
• Good mechanical properties
• Environmentally friendly and harmless
Specifications and Technical Data:
Product Code | Specification | Break Strength | Modulus | Elongation at Break | Finish | Moisture Regain | ||
Denier | g/d | N | GPa | g/d | % | % | % | |
AFY2070 | 200D | 23±1 | 46±2 | 100±5 | 790±40 | 2.5±0.5 | 0.8 | 7 |
400D | 23±1 | 80±3 | 100±5 | 780±40 | 2.7±0.5 | 0.8 | 7 | |
600D | 23±1 | 140±6 | 95±5 | 730±40 | 3.1±0.5 | 0.8 | 7 | |
840D | 23±1 | 201±8 | 90±8 | 700±65 | 3.1±0.5 | 0.8 | 7 | |
1000D | 23±1 | 225±8 | 90±8 | 700±65 | 3.2±0.5 | 0.8 | 7 | |
1500D | 23±1 | 330±15 | 85±8 | 670±65 | 3.2±0.5 | 0.8 | 7 | |
2250D | 23±1 | 500±20 | 80±10 | 650±70 | 3.6±0.5 | 0.8 | 7 | |
3000D | 23±1 | 690±25 | 75±10 | 600±70 | 3.6±0.5 | 0.8 | 7 | |
AFY2090 | 1500D | 22±1 | 330±20 | 115±8 | 900±50 | 2.6±0.5 | 0.8 | 5 |
3000D | 22±1 | 650±30 | 110±10 | 890±50 | 2.6±0.5 | 0.8 | 5 | |
6000D | 22±1 | 1300±60 | 108±10 | 870±50 | 2.6±0.5 | 0.8 | 5 | |
AFY2350 | 400D | 26±1 | 100±5 | 100±5 | 780±40 | 2.7±0.5 | 0.8 | 7 |
600D | 26±1 | 160±8 | 95±5 | 730±40 | 3.1±0.5 | 0.8 | 7 | |
840D | 26±1 | 220±10 | 90±8 | 700±65 | 3.1±0.5 | 0.8 | 7 | |
1000D | 26±1 | 240±12 | 90±8 | 700±65 | 3.2±0.5 | 0.8 | 7 | |
Application:
• Aerospace and military applications such as ballistic protection
• Optical fiber cables, hoses
• Tires, rubber products
• Protective clothing
• Robes and Cables
Storage:
The aramid products should be kept in its original packaging in a dry, clean, and cold location. Best condition is at temperature from 15 to 35°C and Humidity between 35 to 65% to ensure safety，quality and performance.
FAQ
Q: Do you have black aramid yarns?
A: Yes, our aramid yarn is available in black upon special requirements regarding the appearance of the yarns
Q: Do you have any requirements on the MOQ?
A: Yes, we have. It depends on the specification you need.
Q: Can you do OEM for the aramid yarn with special dtex?
A: Yes, we can. We are always here to meet your requirements.
Q: What is the filament diameter?
A: Around 12um
