Aramid Cloth, also called aramid fabric, is woven by para-aramid filament yarns. Aramid fabrics offer a lighter, tougher and more damage tolerant laminate. The aramid cloth can stand temperature of up to +350°C and keeps its abrasion resistance.
Identification:
Appearance | Yellow, Tan, Black, Red, Blue |
Roll Length (mm) | 30000, 50000 |
Width (mm) | 1000, 1300 |
Density (GSM, g/㎡) | 60-630 |
Weave | Plain, Twill, Satin |
Product Features:
• High strength to weight ratio
• Efficient thermal insulation
• Excellent resistance to cutting, abrasion and tearing
• High tenacity and high modulus
• Great softness and flexibility
• Resistance to acids
• Flame retardant and fireproofing
Specification and Technical Data:
Product Code | Break Strength N/5cm | GSM （g/㎡） | Fabric count/10cm | Thickness mm | Width mm | ||
Warp | Weft | Warp | Weft | ||||
AC273 | 5600 | 5600 | 180 | 50 | 50 | 0.24 | 130 |
AC275 | 6500 | 6500 | 200 | 85 | 85 | 0.24 | 130 |
AC277 | 13000 | 13000 | 340 | 150 | 150 | 0.50 | 130 |
AC279 | 14000 | 14500 | 420 | 125 | 125 | 0.67 | 130 |
Application:
• Thermal insulation
• Ballistic protection
• Protection shield
• Gloves and aprons
• Sport equipment
• Construction reinforcement
Storage:
In order to ensure safety, quality and performance, the aramid products should be stored at temperature from 15 to 35°C and Humidity between 35 to 65% and keep its original packaging unpacked until use.
FAQ
Q: Are red aramid fabrics made from genuine aramid fibers?
A: Yes, they are. They are woven by RED aramid yarns, which are dyed in the process of surface treatment.
Q: Do you have coated aramid fabrics?
A: Yes, we have. Silicone coated aramid fabrics are available. Other coatings upon request.
Q: Are all specifications listed above?
A: No, they are not all of our specifications. They are provided by way of indication only. We can produce upon your requirements.
